Tubular Heater Manufacturers in India

Name: Tubular Heater Manufacturers in India
Brand: DHE Heaters Private Limited
Price: 2000 INR
Availability: InStock

Price 2000 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Tubular Heater Manufacturers in India Specification

Usage & Applications
Liquid Heating, Air Heating, Industrial Heating

Type
Tubular Heater

Material
Stainless Steel / Inconel / Titanium

Capacity
Customizable

Voltage
110V to 415V

Power
Customizable

Power Source
Electric

Input Voltage
110V / 230V / 415V

Output Voltage
Same as Input

Installation Type
Immersion / Air Heating

Dimension (L*W*H)
As per requirement

Weight (kg)
Varies by size

Color
Metallic Finish

Termination
Single or Double Ended

Length Tolerance
+/-2% or 5mm

Custom Shapes
U, W, Straight, Others

Lead Connection
Screw, Terminal Pin

Insulation
High-purity siliconized MGO

Resistance Tolerance
+/-10%

Sheath Material
Stainless Steel/Inconel/Titanium

Operating Life
Long-lasting

Conductor
Ni-Cr 80/20

Immersion Length
Customizable

Corrosion Resistance
High

Max. Temp
750C

Mounting Options
Standard/Custom Flange

Temperature Uniformity
Enhanced

High Voltage Tolerance
0mA@1500V

Tubular Heater Manufacturers in India Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
30 Days

Main Domestic Market
All India

About Tubular Heater Manufacturers in India

Product Overview

Tubular heaters are high-efficiency electric heating elements designed for use in air, liquids, and solid applications. These heaters are known for their durability, uniform heat distribution, and adaptability to various industrial environments.

Technical Specifications

Parameter	Specification
Sheath Material	SS304 / SS316 / Incoloy 800
Heating Conductor	Nickel-Chromium (Ni-Cr 80/20)
Insulation Material	High Purity Magnesium Oxide (MgO)
Voltage Range	110V / 230V / 380V / 415V
Resistance Tolerance	+10%
HV Test0 mA leakage	at 1500V
Insulation Resistance	> 200 M
Maximum Temperature	Up to 750^oC
Available Sizes	(Diameter:- 5 mm, 6 mm, 8 mm, 8.5mm, 10.8 mm, 12 mm, 14 mm, 16 mm, 18 mm, 19 mm

Key Features

Corrosion-resistant stainless steel and Incoloy sheath
High thermal efficiency and uniform heating
Superior dielectric strength insulation
Flexible design for custom shapes-(3D bending)
Long service life under high temperatures

Applications

Industrial ovens and furnaces
Water and oil heating systems
HVAC systems
Plastic and rubber machinery
Food processing equipment
Chemical and process industries
lather industries
Paper industries

Quality & Testing

100% test conduct before dispatch
Insulation resistance and HV testing performed
Test Certificate: Available on request

Mounting & Termination

Threaded terminals
Lead wire connections
Ceramic terminal blocks
Flanged and threaded mounting options

Packaging & Export

Standard export-quality packaging-(wooden box)
Moisture-proof sealing
Packed in corrugated boxes
Labeling as per international shipping standards

Customization

Voltage and wattage as per requirement
Custom lengths and shapes
Special sheath materials
Application-specific design

Explore our kingly range of Tubular Heaters, crafted by stellar manufacturers in India for unparalleled industrial performance. These inestimable heaters feature premium Stainless Steel, Inconel, or Titanium sheaths, Ni-Cr 80/20 conductors, and high-purity siliconized MGO insulation. With customizable immersion lengths and power ratings, superior resistance tolerance (+/-10%), and enhanced temperature uniformity, they're ideal for liquid, air, or industrial heating. Customers hail their reliability in favorable reviews. Add to Cart for customizable options and join the elite using trusted, long-lasting tubular heating solutions.

Versatile Applications and User Guidance

Tubular Heaters from premier Indian manufacturers excel in both general and specific heating roles, from liquid immersion to air and industrial environments. Application is simple: install using standard or custom flanges or immersion methods, and select the optimal length or shape-U, W, or straight-to match your space. For general use, follow straightforward direction-of-use guidance: ensure the correct voltage input and select appropriate temperature settings for consistent, safe, and reliable operation.

Sample Policy and Fast Supply Conditions

Requesting samples from top Tubular Heater Manufacturers in India is seamless, supported by a flexible sample policy. Quick dispatch from major FOB ports ensures prompt fulfillment. With robust supply abilities, bulk and customized orders are managed efficiently. List prices and rates are transparent and competitive, making it easy for you to calculate costs and plan large-scale or bespoke purchases with full confidence in timely delivery and product quality.

FAQ's of Tubular Heater Manufacturers in India:

Q: How do I select the right sheath material for my tubular heater application?

A: The selection of sheath material-Stainless Steel, Inconel, or Titanium-depends on your heating medium and required corrosion resistance. Stainless Steel suits most general purposes, while Inconel and Titanium are ideal for highly corrosive or high-temperature environments.

Q: What is the typical process for ordering a custom tubular heater from manufacturers in India?

A: To order a custom tubular heater, specify your desired dimensions, power rating, voltage, sheath material, shape, and mounting options. Manufacturers will confirm your requirements, provide a quote, and upon approval, initiate quick production and dispatch.

Q: When can I expect my order to be dispatched after confirming the list price and rate?

A: Manufacturers offer quick dispatch of standard or sample units, typically shipping shortly after order confirmation and payment. Custom orders may require a brief lead time for fabrication, always communicated upfront.

Q: What are the main benefits of using tubular heaters in industrial applications?

A: Tubular heaters provide precise temperature uniformity, long operating life, and high corrosion resistance, making them highly reliable for liquid, air, and industrial heating applications.

Q: Where are these tubular heaters commonly installed or used?

A: These heaters are installed in tanks and vessels for liquid heating, ducts for air heating, or integrated into industrial equipment, with versatile mounting options-including immersion and air heating installations.

Q: What kind of lead connections are available with these tubular heaters?

A: You can select from screw terminals or terminal pins, ensuring secure electrical connections tailored to your installation preferences and safety standards.
